. Scantronic Leading the way in security. Table 1 (Cont'd). Log Event Codes contents of this book are correct. However, neither the authors nor Scantronic accept any liability for loss or damage caused or alleged to be caused directly or Turning the Chime On/Off.
16 indirectly by this book. Introduction The 9800+ (16 zone) System The 9800+ (16 zone) system comprises a control unit, one or more keypads, and various detectors. The control unit is a steel box that houses the main controller, power supply, stand-by battery, and any remote communicator.
The control unit is normally fitted out of sight in a safe place (for example under the stairs). Introduction Figure 1. 9800+ Keypad The keypad has the following displays and controls: A, B, C LEDs These LEDs (Light Emitting Diodes) glow to show which Level is set. The LEDs are dark when the Levels are unset.
Note that the installer can pro gram the system to hide the display. Introduction whole system. B and C set part of the system. (D is not active.) Note that you will have to use your access code first. Panic Alarm Keys Press keys 1 and 3 together to raise a personal attack alarm. Everyday Operation There are several different ways of setting the system. For all methods (except using a Keyswitch) you must enter your access code at the keypad.
The Keyswitch method uses a key in a special switch fitted to your premises. 'Setting the System'. Everyday Operation Leave via the designated exit route. Close the final door. At the end of the exit time the system sets, and stops the exit tone.
The Level LED glows steadily to show which Level is set. Note: If you change your mind about setting the system either press (Clear) within five seconds of entering your code, or key in your access code again if you miss the first five seconds. Everyday Operation Part Setting The Installer may have programmed your system so that you can protect part of the premises while the rest is in use.
Level keys B and C can give two part set areas, ask your installer which areas each key covers. Close doors and windows in the protected area. Everyday Operation Return to the keypad and set the system again. If no other detectors are active the system sets. Repeat steps 1 to 3 if the display shows other zones. If you still cannot set the system then call the engineer. Unsetting the System Unsetting From a Keyswitch Turn the keyswitch to OFF.
After an Alarm 3. After an Alarm When your system raises an alarm you must disarm it in order to switch off the sounders and strobes. The system keeps a record of which zone(s) triggered the alarms, and shows the zone number(s) on the keypad display. Once you have disarmed the system, the system must be reset before you can start using it again.
After an Alarm Customer Reset Key-in your access code and press (Clear). The Fault LED goes dark and the display clears. You can now use your system as normal. Remote Reset Before starting this process, make sure you have a pen and paper to hand. You will need to write down some information shown on the keypad. Special Functions Introduction You can perform a number of other functions, apart from setting and unset ting the system.
These functions are: Access code + X Setting the system so that some zones are by passed or omitted. Access code + 3 Setting the time and date on the system's internal clock. Special Functions Omitting 24 Hour Zones If your system is fitted with 24 hour detector zones, you may be able to omit them if necessary. For example, your premises may have a fire door that you occasionally open.
Ask your Installer if this is possible. If your system is programmed to allow you to omit a 24 hour zone, then: Key in your access code. Special Functions Key in two digits for the minutes, followed by (Clear). To view the time when the system is unset: Enter User 01 access code. Press 3 followed by (Clear). The system displays two digits for the year. Press (Clear) repeatedly to see, in order, the month, day, hour, and minutes.
Special Functions Key in the access code you wish to change. The display shows 'nc' (new code). Key in the new access code that you wish to use. Note: Do not use 0 (zero) as the first digit of the code. Press (Clear) to store the new code.
Special Functions Table 1 (Cont'd). Log Event Codes Code Meaning Control unit lid tamper † o1 to o16 Zone omitted P1 to P4 Remote keypad dual key PA alarm Mains power failure Print log. R1 to r4 Remote keypad enclosure tamper Remote keypad missing Installer reset Remote keypad excess key presses. Special Functions Walk Test You can set the system so that it will allow you to walk round the premises and test each of the detectors (a walk test). Choose a time when the premises are empty to carry out the test, otherwise people may trigger any movement detectors before you do, and confuse the results of the test. System Faults Your system may light the Fault LED and start an internal alarm to indicate that it has detected a fault.
(An internal alarm is the keypad and internal sounders active, but the external sounder (bell) and strobe quiet.) The display will give a two letter code to indicate what type of fault has occurred. Day contact Tel: Night contact Tel: Company Name: 496247 Issue 4. 496247 Issue 4.
. Microprocessor Intruder Alarm System User Guide SCANTRONIC L TD. Glossary of Terms Access Code User private code (4 Digit) used to set, unset and programme the system. Automatic An optional automatic dialling unit fitted within the Signalling Device alarm control unit and connected via your telephone line to your alarm company central station. Bell-Walk Test A routine test of all alarm detectors and warning devices.
Contents Section Title Page INTRODUCTION.2 OPERATOR CODES AND DISPLAYS.3 OPERATOR CODES. Introduction The 9800 Electronic Intruder Alarm system uses the latest microprocessor technology to provide a simple to operate, yet highly flexible system, suitable for a wide range of small to medium sized protection applications. The system comprises a main control unit, housing the system control printed circuit board and power supplies. Operator Controls and Displays LED Display Complete System Fault LED Omit LED Service LED Program Button Selector Button Mains LED 9 8 0 0 Numeric Keypad POWER Keypad FAULT SERVICE OMIT Sounder System Prog log Indicators chime bell-test-walk Log Button d a y OMIT CLEAR. Normal Setting Ensure that all doors and windows are secure, check that movement detectors are not obstructed and proceed as follows: 9800 9800 POWER POWER FAULT SERVICE OMIT FAULT SERVICE OMIT Prog Prog chime bell-test-walk chime bell-test-walk OMIT OMIT CLEAR CLEAR Enter access code.
Scantronic Usa
Should the user attempt to set the system with one or more zones open, the system will not set. The internal sounder will emit an interrupted tone and the LED display will indicate the open zone, proceed as follows: 9800 9800 POWER. NORMAL KEYSWITCH SETTING The following describes setting the system using the keyswitch and the response of the keypad. 9800 POWER FAULT SERVICE OMIT. Should the user attempt to set the system with the keyswitch when one or more zones are open, the system will not set. The internal sounder will emit an interrupted tone and the LED display will indicate the open zone.
Proceed as follows: 9800 POWER FAULT SERVICE. The Part Set function provides the user with the facility to set the system with only the detection allocated to Group B or C being armed. Circuits not allocated to a Part Set group will not be armed when setting, allowing normal access. 9800 9800 POWER POWER. The user can set or part set the system with selected alarm zones omitted from the system.
(If zone is programmed by engineer for ‘Omit Enabled’.) However certain zones, classified as ‘Non Omit’ cannot be omitted. To set the system with zone(s) omitted, proceed as follows: 9800 9800 POWER POWER. Omitting a 24Hr Zone If necessary, the user can omit a 24hr circuit when the system is unset.
(If zone is programmed by engineer for ‘Omit Enable’.) To omit a 24hr circuit proceed as follows: 9800 9800 POWER POWER FAULT. Unsetting the System On entering the premises the sounder will be emitting a continuous tone.
The user should proceed immediately to the keypad via the prescribed entry route and unset the alarm as follows: 9800 9800 POWER POWER FAULT SERVICE. Your system may be programmed with an ‘Abort’ feature, which works as follows: The 9800 gives a full alarm if the user leaves the entry route or exceeds the entry time. The 9800 sends a ‘Restore’ signal to the central station if the user enters a valid access code at the keypad within 90 seconds of the alarm (avoiding Police action). This ensures that the user contacts the central station to acknowledge accidental alarms or system problems. If the alarm has activated following a genuine intrusion, procedural error or for other reasons, proceed as follows: 9800 9800 POWER POWER FAULT. Remote Reset (Cont.) Call your alarm company central 9800 station, follow the verification POWER FAULT SERVICE OMIT procedure (usually a code name or number) and give the ‘Control Code’.
You will then be given a 4 Prog digit ‘Reset Code’. Unsetting After an Alarm On entering the premises following an intrusion, a full alarm condition will exist.
To cancel the alarm, the user should proceed directly to the remote keypad via the prescribed entry route and proceed as follows: 9800 9800 POWER POWER. ‘Chime’ tone if any normal alarm, entry route or final door zone is opened. Where an exit terminator is fitted, this will act as a door bell when the system is set to chime. To set the system to chime, proceed as follows: 9800 9800 POWER POWER.
Scantronics Security System
The system will accept up to four different user access codes, the first of which is pre-programmed. The user can allocate or amend all four codes at any time, or amend the ‘Duress’ code as follows: 9800 9800 POWER POWER. With the alarm system in the ‘Day’ state, the user can scan the coded event log to obtain a record of system events.
The event log will display events chronologically, with the most recent event first. To scan the event log, proceed as follows: 9800 9800 POWER POWER. Sounder, Bell & Strobe Test The user can test the operation of the internal and external sounders, bell and strobe as follows: 9800 9800 POWER POWER FAULT SERVICE OMIT FAULT SERVICE OMIT Prog Prog chime bell-test-walk chime bell-test-walk OMIT OMIT. System Walk Test The user can ‘Walk Test’ the system and test the operation of each detector circuit (with the exception of panic alarms or fire circuits) as follows: 9800 9800 POWER POWER FAULT SERVICE OMIT FAULT SERVICE OMIT Prog. TELEPHONE LINE FAULT If your system is fitted with a remote signalling device which operates over the standard telephone network, a local alarm condition will warn the user if a telephone line fault exists as follows: 9800 9800 POWER POWER. System Fault Conditions (Cont.) BATTERY FAULT If a battery fault condition occurs when the system is unset, a local alarm condition will be initiated.
To cancel the local alarm, proceed as follows: 9800 9800 POWER POWER FAULT SERVICE OMIT FAULT. However, if the tamper alarm occurs when the system is unset, a local alarm only will be initiated.
Check for any obvious causes and then cancel the alarm as follows: 9800 9800 POWER. Explanation of Codes c1 to 8 Detector circuit open.
T1 to 8 Circuit tamper open. O1 to 8 Detector circuit omitted (isolated).
E1 to 8 Entry via a detector circuit. S1 to 8 Detector circuit on Soak test. Alarm on entry Exit fault Control panel battery fault Mains supply failure. Your Circuit Description ZONE DESCRIPTION WHOLE PART PART OMIT CHIME SYSTEM SET B SET C ALLOWED Installed by (Engineer’s signature).Date Completed. ENGINEER RESET. Service Record DATE REPORT. Your Service Contact COMPANY NAME.ADDRESS.
Manufactured in the UK by Scantronic Ltd. 495665 Issue 2 SCANTRONIC L TD.
